HICLOVER 10-500kgs/Hr.Double Combustion Chambers

hiclover Uncategorized March 2, 2022 | 0

HICLOVER is growing brand for environmental protection field, and market share with most of Africa, Middle East, Southeast Asia countries and part of North America, Europe territory. We are trusted partner for governmental organizations, non-profit organizations, international contractors, logistics organizations, military, pet cremation business owners, etc. We have export experience more than 40 countries, including war zone like Iraq, Afghanistan, Somalia, South Sudan. Mobile: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected]

Phone: +86-13813931455(whatsapp/wechat)
Website: http://www.hiclover.com/

Email: [email protected]
Email: [email protected]

Nanjing Clover Medical Technology Co.,Ltd.

HICLOVER, Nanjing Clover Medical Technology Co.,Ltd, supply system solutions for medical environmental protection, animal and pet cremation engineering, other municipal solid waste incineration project.

HICLOVER Incinerator/Parts Range	Main Feature Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)
Medical Waste Incinerators	HICLOVER 10-500kgs/Hr.Double Combustion Chambers
Single Combustion Chamber	Small, Cheap,10-20kgs/Hr.
Three Combustion Chambers(Optional) Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)	3 Chambers for high risk waste
Pet Cremation Equipment	For Pet(small/big) Cremation Business
Animal Incineration Equipment	For other animal incineration

Items/Model	TS100(PLC) Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)	TS150(PLC)	TS300(PLC)	TS500(PLC)
Burn Rate (Average)	100 kg/hour	150 kg/hour	300 kg/hour	500 kg/hour Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)
Control Mode	PLC Auto.	PLC Auto.	PLC Auto.	PLC Auto.
Combustion Chamber	1200L Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)	1500L	2000L	3000L
Internal Dimensions	120x100x100cm	150x100x100cm	170x120x100cm	210x120x120cm
Secondary Chamber	600L Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)	750L	1000L	1500L
Smoke Filter Chamber	Dry Scrubber	Dry Scrubber	Dry Scrubber	Dry Scrubber
Feed Mode	Manual Nanjing Clover Medical Technology Co.,Ltd. Tel: +86-13813931455(WhatsApp) Website: www.hiclover.com Email: [email protected] Email: [email protected] Add: Gangjia Zhihui Industrial Area, Xin Gangwan Rd. Liuhe, Nanjing, China 211500 HICLOVER Solution for Fighting COVID-19, with ISO9001/CE Certification. Auto. Control Waste Incinerator & Auto. Roll Air Filter(Air Purification)	Manual	Manual	Manual
Voltage	220V	220V	220V	220V
Power	1.38Kw	1.69Kw	2.57Kw	4.88Kw
Diesel Oil Consumption (kg/hour)	Ave.20.4	Ave.24.2	Ave.33	Ave.44
Natural Gas Consumption (m3n/hour)	Ave.24.5	Ave.29	Ave.39.6	Ave.52.8
Temperature Monitor	Yes	Yes	Yes	Yes
Temperature Protection	Yes	Yes	Yes	Yes
Oil Tank	200L	300L	500L	500L
Chimney	10Meter	10Meter	14Meter	14Meter
Chimney Type	Stainless Steel	Stainless Steel	Stainless Steel	Stainless Steel
1st. Chamber Temperature	800℃–1000℃	800℃–1000℃	800℃–1000℃	800℃–1000℃
2nd. Chamber Temperature	1000℃-1200℃	1000℃-1200℃	1000℃-1200℃	1000℃-1200℃
Residency Time	2.0 Sec.	2.0 Sec.	2.0 Sec.	2.0 Sec.
Gross Weight	6000kg	8500kg	11000kg	16000kg
External Dimensions	260x150x180cm	300x160x190cm	400x210x300cm	450x210x300cm

TECH SPECS FOR 200KGHOUR INCINERATOR

The lower calorific power (L.C.P) of this waste will be 3,500 kcal/kg

The Temperatures of combustion: Minimum will be 850oC and max 1400oC

Post combustion: >1100oC.

The Internal diameter of the Chimney: Ø 400mm² and its height: 8 m

The Volume of the combustion chamber: 1.200 L

The Dimension of the door for loading in cm: 70×70.



* Burner with fuel, mono-bloc casting guiding type with horizontal flame, lighting and safety of electronic ignition, permanent ventilation, electromagnetic sluice gate of regulation and isolating valve.

* A secondary injection of air to ensure perfect oxygen content.

A control box ensuring the complete cycle of combustion.

Fan:

* Electro-ventilator distributing the secondary air, the regulation of the air flow being carried out by valves and following the control of the automatic cycle.

Controls and regulations:

Control box water tight to dust, including:

* A switch circuit breaker for each engine (ventilators and burners).

* A timer with adjustable temporization for the regulation of each burner.

* A regulator with digital watching for the temperature of combustion.

* A regulator with digital watching for the temperature of post combustion.

* Electric box.

The de- ashing must be done in the bottom of the combustion chamber or the deashing should be Automatic or manual batch de ashing.

Process Filtering system: Scruber to be mentioned as optional

Emission Standards Compliance: BS 3316 or equivalent standard

Capacity to treat Plastic: Not less than 40% by weight

The supplier must give batches of spare parts of first urgency and consumable of the incinerator.

The installed incinerator must bear a one year guarantee.

The supplier shall perform an onsite installation of the incinerator.

The technical training of operators will have to be provided and given by a technician from

the factory; it will consist of curative and preventive maintenance, and the use of machine, etc

Fence Wire for Incinerator House (Chain Link) should be NOT less than 2.5Meters height.

Waste Storage Bay and Ash Pit drawings attached.

This material and equipment must include in the shed of the incinerator: foundation in rubble stone, isolation roofing against humidity; elevation with brick of 20 cm (bloc cement), continuing lintel (linteau) in reinforced concrete; steel frame (charpenteen metal);
